| 技術參數- - 定性濾紙標準級 | ||||||
| Grade | 描述 |
液體中顆粒
保留(μm)
|
過濾速度（大約值）
Herzberg (s)
|
空氣流速
(s/100 ml/in2）
|
厚度(μm) |
基本重量
(g/m2）
|
| 1 | 中等流速 | 11* | 150 | 10.5 | 180 | 88 |
| 2 | 中等流速 | 8* | 240 | 21 | 190 | 103 |
| 3 | 中等流速，厚 | 6* | 325 | 26 | 390 | 187 |
| 4 | 很快 | 20-25* | 37 | 3.7 | 205 | 96 |
| 5 | 慢速 | 2.5* | 1420 | 94 | 200 | 98 |
| 6 | 由中到慢 | 3* | 715 | 35 | 180 | 105 |
| 591 | 中快，厚 | 7-12** | 45 | 5.9 | 350 | 161 |
| 595 | 中快，薄 | 4-7** | 80 | - | 150 | 68 |
| 597 | 中快 | 4-7** | 140 | - | 180 | 85 |
| 598 | 中快，厚 | 8-10** | 50 | - | 320 | 140 |
| 602h | 慢速，稠密 | <2** | 375 | - | 160 | 84 |
| * 顆粒保留率：液體中濾紙對標準顆粒物截留度在98%以上 | ||||||
| ** 近似值 | ||||||
| 訂貨信息-定性濾紙（圓圈型）--標準級 | |||||||
| 尺寸 (mm) | 貨號 | ||||||
| Grade 1 | Grade 2 | Grade 3 | Grade 4 | Grade 5 | Grade 6 | 數量/包 | |
| 10 | 1001-6508 | - | - | - | - | - | 500 |
| 15 | 1001-0155 | - | - | - | - | - | 500 |
| - | - | - | - | - | - | - | 400 |
| 20 | 1001-020 | - | - | - | - | - | 400 |
| 23 | - | - | 1003-323 | - | - | - | 100 |
| 25 | 1001-325 | - | - | 1004-325 | 1005-325 | - | 100 |
| 25 | 1001-025 | - | - | - | - | - | 400 |
| 27 | - | - | - | 1004-027 | - | - | 400 |
| 30 | 1001-329 | - | - | - | - | - | 100 |
| 30 | 1001-030 | - | - | - | - | - | 400 |
| 32 | 1001-032 | - | - | - | - | - | 100 |
| 42.5 | 1001-042 | 1002-042 | - | 1004-042 | 1005-042 | 1006-042 | 100 |
| 47 | 1001-047 | 1002-047 | - | 1004-047 | 1005-047 | - | 100 |
| 50 | - | - | - | 1004-050 | - | - | - |
| 55 | 1001-055 | 1002-055 | 1003-055 | 1004-055 | 1005-055 | - | 100 |
| 70 | 1001-070 | 1002-070 | 1003-070 | 1004-070 | 1005-070 | 1006-070 | 100 |
| 85 | 1001-085 | - | - | - | - | - | 100 |
| 90 | 1001-090 | 1002-090 | 1003-090 | 1004-090 | 1005-090 | 1006-090 | 100 |
| 94 | - | 1002-094 | - | - | - | - | 1000 |
| 110 | 1001-110 | 1002-110 | 1003-110 | 1004-110 | 1005-110 | 1006-110 | 100 |
| 125 | 1001-125 | 1002-125 | 1003-125 | 1004-125 | 1005-125 | 1006-125 | 100 |
| 150 | - | 1002-147 | - | - | - | - | 100 |
| 150 | 1001-150 | 1002-150 | 1003-150 | 1004-150 | 1005-150 | 1006-150 | 100 |
| 185 | 1001-185 | 1002-185 | 1003-185 | 1004-185 | 1005-185 | 1006-185 | 100 |
| 240 | 1001-240 | 1002-240 | 1003-240 | 1004-240 | 1005-240 | 1006-240 | 100 |
| 270 | 1001-270 | 1002-270 | - | 1004-270 | - | - | 100 |
| 320 | 1001-320 | 1002-320 | 1003-320 | 1004-320 | 1005-320 | - | 100 |
| 385 | 1001-385 | 1002-385 | - | - | - | - | 100 |
| 400 | 1001-400 | - | - | 1004-400 | - | - | 100 |
| 500 | 1001-500 | 1002-500 | 1003-500 | - | 1005-550 | - | 100 |
| 訂貨信息-定性濾紙（圓圈型）--標準級 | |||||
| 尺寸 (mm) | 貨號 | ||||
| Grade 595 | Grade 597 | Grade 598 | Grade 602h | 數量/包 | |
| 12.7 | - | 10311862 | - | - | 1000 |
| 42.5 | - | - | - | - | 100 |
| 45 | - | 10311804 | - | - | 100 |
| 55 | - | 10311807 | - | - | 100 |
| 70 | - | 10311808 | - | - | 100 |
| 90 | - | 10311809 | 10312209 | - | 100 |
| 110 | 10311610 | 10311810 | - | - | 100 |
| 125 | 10311611 | 10311811 | - | 10312611 | 100 |
| 150 | 10311612 | 10311812 | - | 10312612 | 100 |
| 195 | - | 10311814 | - | 10312614 | 100 |
| 240 | - | 10311820 | - | 10312620 | 100 |
| 320 | - | 10311822 | - | - | 100 |
| 訂貨信息-定性濾紙（方片型）--標準級 | |||||
| 尺寸 (mm) | 貨號 | 數量 | 尺寸 (mm) | 貨號 | 數量 |
| Grade 1 | Grade 4 | ||||
| 25 × 31 | 1001-813 | 1000 | 460 × 570 | 1004-917 | 100 |
| 75 × 100 | 1001-824 | 500 | 590 × 590 | 1004-930 | 100 |
| 460 × 570 | 1001-917 | 100 | Grade 591 | ||
| 460 × 570 | 1001-918 | 500 | 590 × 590 | 10311387 | 250 |
| 590 × 690 | 1001-931 | 100 | Grade 595 | ||
| 590 × 690 | 1001-932 | 500 | 590 × 590 | 10311687 | 500 |
| 600 × 600 | 1001-929 | 100 | Grade 597 | ||
| Grade 2 | 590 × 590 | 10311887 | 500 | ||
| 590 × 690 | 1002-931 | 100 | 590 × 590 | 10311897 | 100 |
| 600 × 600 | 1002-929 | 100 | Grade 598 | ||
| Grade 3 | 590 × 590 | 10312287 | 250 | ||
| 305 × 457 | 1003-433 | 100 | |||
| 460 × 570 | 1003-917 | 100 | |||
| 590 × 590 | 1003-930 | 100 | |||
